model:Single axis/Dual-axis
capability:300-5000KG/H
Discharge size:20-100mm
Tool life:≥ 3000 hours
Medical waste shredder is a kind of equipment specially used for processing medical waste. Its main function is to tear various types of medical waste into small pieces for subsequent treatment, such as incineration, disinfection or landfill, etc. Medical waste shredder is mainly composed of blade spindle, fixed blade, bearing box, box bracket, feeding system, hydraulic pushing system, power system and electrical control system.
The working principle of the medical waste shredder is to feed the medical waste into the shredding box through the feeding system. The material is shredded into small pieces by the tearing, squeezing and shearing action of the shredding blades and then discharged from the screen holes. This design enables the equipment to efficiently process various medical wastes, such as medical masks, surgical gowns, syringes, etc.
Medical waste shredders are suitable for the treatment of various types of medical waste, including but not limited to medical masks, surgical gowns, syringes, discarded medicines, etc. By shredding medical waste into small pieces, the treatment efficiency can be greatly improved and the transportation and treatment costs can be reduced.
| Parameter classification | Single axis model | Dual-axis model | Common technical indicators |
| Processing capacity | 300-5000 kg/h | customized | Discharge particle size: 20-100mm (adjustable screen) |
| Power configuration | 18.5kW motor, hydraulic push system (stroke 500mm) | 15-110kW motor | Comply with medical waste disposal safety regulations |
| Tool system | 23 moving knives + 3 fixed knives (high wear-resistant alloy) | 15-30 tooth cutters (SKD11 material, HRC60°+heat treatment) | Support tool repair, life ≥ 3000 hours |
| Structural design | Feeding port 800×600mm, hopper 760L, knife roller length 600mm | Tooth cutter diameter 200-550mm | Sealed crushing chamber, splash-proof design |
| Intelligent control | Optional PLC control | Standard PLC, supports automatic overload reversal and status monitoring | Support remote monitoring (some high-end models) |
| Applicable scenarios | Continuous treatment of infectious waste, plastic infusion bottles and other medium-hard materials | Mixed hard waste (including metal equipment, glass products, etc.)） | Meet the needs of subsequent treatment such as incineration and high-temperature sterilization |
| Safety protection | Adjustable push guide bar, emergency stop button | Overload protection, automatic shutdown alarm | Some models integrate UV/high-temperature disinfection modules |
| Customized options | Adjustable screen (20/40mm), motor power upgrade | Supports optimization of tooth knife arrangement and customization of feed port size | Provide anti-corrosion coating (optional when treating chemical medical waste) |
waste type:solid/liquid type medical waste
structure type:horizontal type
capacity:20kg/hr-1000kg/hr;Customized on demand
shipping way:by sea.by land,by air,all ok,depends on your site place
waste type:all kinds of animal ,such as dog,pig,cat.etc
structure type:horizontal type
capacity:20kg /hr-1000kg/hr;Customized on demand
dimension:can be customized based on your local
waste type:various kinds of industrial waste
structure:horizontal. vertical type
capacity:1-300 ton per day
shipping way:by sea.by land,by air,all ok,depends on your site place
